Solid D Rubber Fenders Reliable Shoreline Defense with Easy Installation Design
Description
This upgraded D Type Fender integrates a UHMW-PE pad on the front face to minimize hull friction and enhance wear resistance. It is ideal for ferry terminals, passenger docks, and areas with frequent vessel contact where smooth berthing is essential.
Hongruntong Marine combines tough rubber resilience with ultra-low-friction pads to create a hybrid fender system with reduced maintenance needs. This configuration significantly reduces vessel hull wear and extends the lifespan of both the fender and marine structures.
Specifications
Product Name | D Type Fenders |
Brand Name | Hongruntong Marine |
Material | High Performance Natural Rubber |
Color | Black and Customers' Requirements |
Type | Fixed D Rubber Fenders |
Standard | HGT2866-2016, PIANC2002 |
Energy Absorption | 147kN to 920kN |
Reaction Force | 5.1KN-M to 64KN-M |
Application | Port, Dock, Quay, etc |
A | B | C | D | E | F | H | K |
[mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] |
70 | 30 | 15 | 30 | 45 | 80 | 90 - 130 | 200 - 300 |
100 | 45 | 15 | 30 | 50 | 100 | 90 - 130 | 200 - 300 |
125 | 60 | 20 | 40 | 60 | 125 | 110 - 150 | 250 - 300 |
150 | 75 | 20 | 40 | 75 | 150 | 110 - 150 | 250 - 300 |
150 | 80 | 25 | 50 | 100 | 200 | 130 - 180 | 300 - 400 |
200 | 100 | 25 | 50 | 100 | 200 | 130 - 180 | 300 - 400 |
200 | 100 | 30 | 60 | 125 | 250 | 140 - 200 | 350 - 450 |
250 | 125 | 30 | 60 | 125 | 250 | 140 - 200 | 350 - 450 |
300 | 150 | 30 | 60 | 150 | 300 | 140 - 200 | 350 - 450 |
350 | 175 | 35 | 75 | 175 | 350 | 140 - 200 | 350 - 450 |
380 | 190 | 35 | 75 | 190 | 380 | 140 - 200 | 350 - 450 |
300 | 150 | 35 | 75 | 175 | 400 | 140 - 200 | 350 - 450 |
400 | 200 | 35 | 75 | 200 | 400 | 140 - 200 | 350 - 450 |
500 | 250 | 45 | 90 | 250 | 500 | 160 - 230 | 400 - 500 |
*Note: Other sizes can be customized according to the requirements. |
A | B | C | D | E | F | G | H | K |
[mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] |
100 | 25 | 10 | 30 | 15 | 100 | 50 | 90 - 130 | 200 - 300 |
150 | 30 | 12 | 65 | 20 | 150 | 75 | 110 - 150 | 250 - 350 |
200 | 45 | 15 | 75 | 25 | 200 | 100 | 130 - 180 | 300 - 400 |
250 | 50 | 20 | 100 | 30 | 250 | 125 | 140 - 200 | 350 - 450 |
300 | 60 | 25 | 125 | 30 | 300 | 150 | 140 - 200 | 350 - 450 |
350 | 70 | 25 | 150 | 35 | 350 | 175 | 140 - 200 | 350 - 450 |
400 | 80 | 30 | 175 | 35 | 400 | 200 | 140 - 200 | 350 - 450 |
400 | 80 | 30 | 200 | 35 | 400 | 200 | 140 - 200 | 350 - 450 |
500 | 100 | 30 | 250 | 35 | 500 | 250 | 140 - 200 | 350 - 450 |
Features
Versatile Mounting Options
Can be mounted horizontally or vertically with bolts, brackets, or
embedded plates.
Available in Multiple Sizes
Offered in a wide range of diameters and lengths to suit different
vessel and dock types.
Custom Lengths Available
Can be cut to customer-specified lengths to reduce waste and
optimize installation.
Optional Pre Drilled Holes
Ready-to-install with customized hole patterns to save time
on-site.
Applications
● Commercial ports
Advantages
Fast Prototyping Sample Production
Quick turnaround for samples and urgent projects with flexible
capacity.
Corrosion Free Low Maintenance Design
Our rubber fenders are long-lasting and require minimal
after-installation care.
Optional Reinforcement Mounting Hardware
Available with steel inserts, chamfered ends, or pre-drilled holes
as needed.
Environmentally Friendly Materials
Use of recyclable rubber and eco-conscious manufacturing processes.
FAQ
1. Q: How long is the production lead time?
A: Standard orders are usually completed within 7–20 working days
depending on the quantity and customization.
2. Q: Do your products comply with international standards?
A: Yes, all our marine fenders are produced in accordance with ISO
and PIANC standards.
3. Q: Can you provide installation accessories with the fenders?
A: Yes, we can supply mounting bolts, steel plates, and other
installation kits if requested.
4. Q: How should D fenders be installed?
A: They can be installed using bolts through pre-drilled holes or
mounted with brackets, depending on the design.
![]() |
