500h Cone Fender High Energy Absorption Low Reaction Force Space Saving Design

Hongruntong Marine Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap 500h Cone Fender High Energy Absorption Low Reaction Force Space Saving Design from wholesalers

    Buy cheap 500h Cone Fender High Energy Absorption Low Reaction Force Space Saving Design from wholesalers
    • Buy cheap 500h Cone Fender High Energy Absorption Low Reaction Force Space Saving Design from wholesalers
    • Buy cheap 500h Cone Fender High Energy Absorption Low Reaction Force Space Saving Design from wholesalers
    • Buy cheap 500h Cone Fender High Energy Absorption Low Reaction Force Space Saving Design from wholesalers
    • Buy cheap 500h Cone Fender High Energy Absorption Low Reaction Force Space Saving Design from wholesalers

    500h Cone Fender High Energy Absorption Low Reaction Force Space Saving Design

    Ask Lasest Price
    Brand Name : Hongruntong Marine
    Model Number : HM-CRF254
    Certification : ISO, BV, ABS, DNV, LR, SGS, CCS, RMRS
    Price : USD50-USD2585
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 2541 PCS Per Month
    Delivery Time : 5-8 Work Days
    • Product Details
    • Company Profile

    500h Cone Fender High Energy Absorption Low Reaction Force Space Saving Design

    500h Cone Fender High Energy Absorption Low Reaction Force Space Saving Design


    Description


    Cone Rubber Fenders maintain excellent energy absorption and low reaction forces even when impacted at angles up to 10–15 degrees. This makes them particularly effective in real docking scenarios, where vessels often make contact at an angle due to wind, current, or operator adjustments. Their geometry helps distribute loads evenly, minimizing localized stress and damage both to the fender and the hull.


    500h Cone Fender High Energy Absorption Low Reaction Force Space Saving Design500h Cone Fender High Energy Absorption Low Reaction Force Space Saving Design500h Cone Fender High Energy Absorption Low Reaction Force Space Saving Design


    Specifications


    Product NameCone Rubber Fenders
    Brand NameHongruntong Marine
    MaterialHigh Quality NR
    StandardPIANC, HGT
    Face PadsUHMW-PE Available
    CertificatesBV, ABS, DNV, LR, SGS, RS, CCS
    OEM / ODMWelcome
    Packing DetailsPe Plastic Bags Then to The Pallet / as Per Your Request
    Production Capacity3000 Pcs Per Month
    Lead Time7 Days for Prototype Tooling & Samples, 14 Days for Production Mold, 14-28 Days for Moq
    Payment TermsT/T, L/C, Paypal, Western Union
    Rubber SpecificationASTM D2000, SAE J200

    ModelHhFDQWd-md-n
    Cone[mm][mm][mm][mm][mm][mm][mm][mm]
    HM-CRF30030013.5255450195405M1620
    HM-CRF35035025300570235510M2025
    HM-CRF40040018340600260540M2025
    HM-CRF50050025425750325675M2430
    HM-CRF60060027510900390810M2430
    HM-CRF700700325851050455945M3038
    HM-CRF8008003668012005201080M3644
    HM-CRF9009004176513505851215M3644
    HM-CRF100010004585015006501350M4256
    HM-CRF1050105055103016809001530M3644
    HM-CRF110011005093516507151485M4250
    HM-CRF115011505299817257501550M4256
    HM-CRF1200120054102018007801620M4250
    HM-CRF1300130059110519508451755M4860
    HM-CRF1400140066119021009301890M4860
    HM-CRF16001600721360240010602160M4870
    HM-CRF18001800781530288011902430M5676
    HM-CRF20002000801900320015402920M5676

    Features


    High Energy Absorption

    Engineered to absorb substantial impact energy, safeguarding both vessel and berth infrastructure.

    Low Reaction Force

    Delivers a low reaction force relative to its energy absorption capacity, minimizing stress on the vessel hull.

    Excellent Shear Stability

    Provides robust resistance to shear forces, critical for accommodating angled berthing and dynamic movements.

    Optimized Geometry

    The conical shape is precisely designed for efficient energy absorption and optimal load distribution.


    Applications


    Military Harbors

    Docking Facilities for Small Vessels
    Docking Stations for Research Vessels
    Wind Farm Service Ports
    Coastal Protection Zones

    Advantages


    Precision Manufacturing

    Focusing on precision and accuracy in every step of the production process.

    Technical Support and After Sales Service

    Providing expert technical assistance and reliable after-sales support.

    Competitive Pricing

    Offering competitive pricing while maintaining high quality standards.

    Flexibility in Production

    Ability to adapt to varying order sizes and production schedules.


    500h Cone Fender High Energy Absorption Low Reaction Force Space Saving Design


    FAQ


    1. What are Cone Rubber Fenders?
    Cone Rubber Fenders are a type of marine fender characterized by their conical shape, designed for high energy absorption and low reaction force during vessel berthing.


    2. What are the main advantages of using Cone Rubber Fenders?
    Key advantages include high energy absorption, low reaction force, excellent shear stability, long service life, and suitability for high-energy berthing applications.


    3. How do Cone Rubber Fenders work?
    Their conical shape allows them to compress and deform under impact, absorbing the kinetic energy of the berthing vessel and distributing the load effectively.


    4. What makes the conical shape beneficial?
    The conical shape optimizes the fender's energy absorption capacity and provides superior stability against shear forces, which are common during angled berthing.
