    Resistant To UV Radiation Jumbo Fender Customizable Dimensions Long Lifespan

    Ask Lasest Price
    Brand Name : Hongruntong Marine
    Model Number : HM-PRF02
    Certification : ISO, BV, ABS, DNV, LR, SGS, CCS, RMRS
    Price : USD9-USD150
    Payment Terms : T/T, L/C, D/A, , D/P, Western Union, MoneyGram
    Supply Ability : 2080 Pcs/Month
    Delivery Time : 10-20 Days
    • Product Details
    • Company Profile

    Resistant To UV Radiation Jumbo Fender Customizable Dimensions Long Lifespan

    Resistant To UV Radiation Jumbo Fender With Customizable Dimensions And Long Lifespan


    Description


    Pneumatic rubber fenders, also known as Yokohama fenders, are widely used in the maritime industry to prevent damage during ship docking and berthing operations. Constructed with reinforced rubber layers and filled with compressed air, they offer excellent shock absorption, reducing impact forces between vessels or between a vessel and the dock. Their flexible design allows them to adapt to different ship sizes and operating conditions. These fenders are corrosion-resistant, making them ideal for long-term use in harsh marine environments. With outstanding stability and self-floating characteristics, pneumatic rubber fenders are a trusted solution for ensuring safe and efficient port operations.


    Resistant To UV Radiation Jumbo Fender Customizable Dimensions Long LifespanResistant To UV Radiation Jumbo Fender Customizable Dimensions Long Lifespan


    Specifications


    Place of Origin

    China

    Brand Name

    Pneumatic Rubber Fender

    Material

    Natural Rubber

    Color

    Black

    Application

    In ports with extreme tidal variations

    Ship-to-ship lightering operations

    Oil Gas (typically FSRU)

    Temporary berthing

    Feature

    Heat Resistance

    Sample

    Usually free

    Production Method

    Moulding

    Temperature

    -40℃~300℃

    Packing

    Pallets

    Lead time

    7-14 days


    Diameter x Length
    [mm]

    50kPa
    Performance Data

    80kPa
    Performance Data

    Hull Pressure
    at GEA
    / kN / m2

    Reaction Force
    / kN

    Energy Absorption
    / kNm

    Hull Pressure
    at GEA
    / kN / m2

    Reaction Force
    / kN

    Energy Absorption
    / kNm

    1000 x 1500

    122

    182

    32

    160

    239

    45

    1000 x 2000

    132

    257

    45

    174

    338

    63

    1200 x 2000

    126

    297

    63

    166

    390

    88

    1350 x 2500

    130

    427

    102

    170

    561

    142

    1500 x 3000

    153

    579

    153

    174

    761

    214

    1700 x 3000

    128

    639

    191

    168

    840

    267

    2000 x 3500

    128

    875

    308

    168

    1150

    430

    2500 x 4000

    137

    1381

    663

    180

    1815

    925

    2500 x 5500

    148

    2019

    943

    195

    2653

    1317

    3300 x 4500

    130

    1884

    1175

    171

    2476

    1640

    3300 x 6500

    146

    3015

    1814

    191

    3961

    2532

    3300 x 10600

    158

    5257

    3067

    208

    6907

    4281

    4500 x 9000

    146

    5747

    4752

    192

    7551

    6633

    * Other size can be produced follow client's requirements.


    Features


    Long Service Life
    Constructed from high-quality materials with excellent resistance to aging and environmental stress, pneumatic fenders offer an extended operational lifespan.


    Cost Effective Maintenance
    With minimal maintenance requirements, these fenders provide a long-term, low-cost solution for vessel and port protection.


    Excellent Performance in Harsh Conditions
    Designed to withstand high winds, strong currents, and extreme weather, ensuring reliable operation in demanding marine environments.


    High Pressure Resistance
    Engineered to endure significant pressure changes without compromising performance, making them ideal for large vessel applications.


    Applications


    Barge and Tugboat Operations


    Ship Repair and Maintenance Areas


    Floating Bridges and Caissons


    Chemical and LNG Terminal Operations


    Advantages


    Versatile Applications
    Suitable for ship-to-ship (STS), ship-to-dock (STD), and offshore platform applications, making them ideal for various marine operations.


    Easy Installation and Relocation
    Lightweight and portable, our fenders can be quickly deployed, repositioned, or stored without the need for heavy lifting equipment.


    Long Service Life
    Engineered for durability, our fenders offer an extended operational lifespan, reducing the need for frequent replacements.


    Minimal Maintenance Required
    Designed for long-term use with minimal upkeep, our fenders offer a cost-effective solution for port and vessel protection.


    Resistant To UV Radiation Jumbo Fender Customizable Dimensions Long Lifespan


    FAQ


    1. How do you install a pneumatic rubber fender?
    They can be hung using chains, shackles, and ropes, either between ships or along docks, depending on the application.


    2. Do pneumatic rubber fenders require maintenance?
    They require minimal maintenance, mainly periodic pressure checks, visual inspections, and cleaning to remove debris and marine growth.


    3. What is the working pressure of a pneumatic rubber fender?
    The standard pressure is either 50 kPa (low-pressure) or 80 kPa (high-pressure), depending on the application and customer requirements.


    4. What happens if a pneumatic rubber fender gets punctured?
    If punctured, the fender may lose air and require repair. Small damages can be patched, while severe damage may require replacement.
