    Iso17357 Yokohama Floating Pneumatic Rubber Fenders For Sts Operations

    Ask Lasest Price
    Brand Name : DockFender
    Model Number : DF-YF3300
    Certification : ISO17357-1:2014, PIANC
    Price : USD200-USD1300 / Piece
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 600 PCS Per Month
    Delivery Time : 5 Work Days
    • Product Details
    • Company Profile

    Iso17357 Yokohama Floating Pneumatic Rubber Fenders For Sts Operations

    ISO17357 Specifications Yokohama Fenders Floating Fender for STS Operations


    Net-type fenders are covered with a chain net, wire net or fiber net for fenders. Usually these nets have used-tires together with rubber sleeves for additional protection, except fiber net which has only rubber sleeves. Chain nets last longer against corrosion, while wire nets are light and more easily repaired.


    Yokohama fenders have become an ideal ship protection medium against collision among ship-to-ship (STS), ship to quay (STQ) and ship-to-berthing (STB), they are widely used for large tankers, vessels, docks, harbor wharfs and ocean platforms.


    The yokohama fender is specifically designed for heavy duty marine and offshore use. The construction of the fender makes it ideal for protecting ships and quays from the forces involved when mooring, either ship-to-ship or ship-to-quay.


    Our fender is manufactured and tested in accordance with ISO 17357:2014-1. This is the only standard ensuring high quality fenders. Each fender can be supplied with individual class certificate (ABS) showing conformance to ISO 17357:2014-1.


    Features


    1. High energy absorption with a low reaction force.
    2. Light weight, portable and floatable, can be installed and replaced easily.
    3. Heavy duty and long service life-over 10 years.
    4. Supplied as sling type (body only) or with chain and tire net for protection of the fender body.
    5. Suitable for locations with large and small tidal differences.


    Applications


    ● Oil and gas tankers

    ● Fast ferries and aluminium vessels

    ● Temporary and permanent installations

    ● Rapid response and emergencies

    ● Can support large panels

    ● Very low reaction and hull pressure

    ● Suitable for small and large tidal ranges

    ● Maintains large clearances between hull and structure


    Fender Structure


    1. Outer layer
    Cover outside on the ball of rubber layer, which is used to protect skeleton material and inner rubber ball from damage of external force.


    2. Reinforced layer
    Reinforced cord rubber layer is composed of winding synthetic cord layer, it is mainly used for maintain the internal air pressure.


    3. Inner Rubber
    On the ball inside the rubber layer, which is used to prevent air leakage and control the ball pressure.


    4. End Flange
    The metal parts at both ends of fender, which can be fitted with charging valve and safety valve.


    SpecificationInitial pneumatic pressure 50KPaInitial pneumatic pressure 80KPa
    D*L(mm)R(KN)GEA (KJ)R(KN)GEA (KJ)
    500*1000646858
    600*10007489811
    700*15001371718024
    1000*15001823223945
    1000*20002574533863
    1200*20002976339088
    1350*2500427102561142
    1500*3000579153761214
    1700*3000639191840267
    2000*3000750265985368
    2000*35008753081150430
    2500*400013816631815925
    2500*5500201994326531317
    3000*50002104121027091571
    3000*60002583148532921888
    3300*45001884117524761640
    3300*65003015181439612532
    3300*106005257306769074281
    4500*65004150343254534790
    4500*90005747475275516633
    4500*1200079846473104909037
