    Iso Standard Yokohama Pneumatic Fender 3.3*6.5m 50 Kpa For Dock

    Ask Lasest Price
    Brand Name : DockFender
    Model Number : DF-3300*6500
    Certification : ISO17357-1:2014
    Price : USD580-2100 One Piece
    Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 2650 PCS Per Month
    Delivery Time : 6 Work Days
    • Product Details
    • Company Profile

    Iso Standard Yokohama Pneumatic Fender 3.3*6.5m 50 Kpa For Dock

    ISO17357-1:2014 Standard Yokohama Pneumatic Fender 3.3*6.5m 50kPa For Dock


    Description


    Pneumatic rubber fenders have become an ideal ship protection medium against collision among ship-to-ship (STS), ship to quay (STQ) and ship-to-berthing (STB), they are widely used for large tankers, vessels, docks, harbor wharfs and ocean platforms.

    Pneumatic Yokohama fenders of diameter 2500mm and larger sizes shall be equipped with a safety valve for releasing excess internal pressure
    when the fenders are over-compressed accidentally. Fender which is smaller than 2500mm in diameter can also be equipped with a safety valve if requested.


    Specifications


    Place of OriginChina
    Brand NameDockFender
    Model NumberDF-YF4500
    MaterialNatural Rubber
    ColorBlack
    Application

    In ports with extreme tidal variations

    Ship-to-ship lightering operations

    Oil & Gas (typically FSRU)

    Temporary berthing

    NameISO17357-1:2014 Standard Yokohama Pneumatic Fender 3.3*6.5m 50kPa For Dock
    FeatureHeat Resistance
    SampleUsually free
    Production MethodMoulding
    Temperature~40-120 degree
    PackingPallets
    Lead time7-14 days

    Diameter x Length
    [mm]
    50kPa
    Performance Data
    80kPa
    Performance Data
    Hull Pressure
    at GEA
    / kN / m2
    Reaction Force
    / kN
    Energy Absorption
    / kNm
    Hull Pressure
    at GEA
    / kN / m2
    Reaction Force
    / kN
    Energy Absorption
    / kNm
    1000 x 15001221823216023945
    1000 x 20001322574517433863
    1200 x 20001262976316639088
    1350 x 2500130427102170561142
    1500 x 3000153579153174761214
    1700 x 3000128639191168840267
    2000 x 35001288753081681150430
    2500 x 400013713816631801815925
    2500 x 5500148201994319526531317
    3300 x 45001301884117517124761640
    3300 x 65001463015181419139612532
    3300 x 106001585257306720869074281
    4500 x 90001465747475219275516633
    * Other size can be produced follow client's requirements.

    Features


    1. High energy absorption.

    2. Super low reaction force.

    3. The inclined contact is good during the operation.

    4. Thick outer skin supersedes that of a normal surface fender.

    5. The rubber pneumatic fender will be floating on the water, even the ship swings, it can be applied.


    Applications


    ● Submarines

    ● Semi-submersible oil rigs

    ● Ship to ship transfer

    ● Ship to shore

    ● Bunkering

    ● Port high tidal variations

    ● Temporary berthing

    ● Large standoff


    Advantages


    Our pneumatic fender as a protective medium is suitbale for ship to ship contact, ship to dock and ship to berthing.
    It is light weight,portable and floatable, can be installed, replaced easily and reused 6-8 years without misuse.
    We have provided pneumatic fenders to marine service and offshore service for varieties ships.
    Low reaction force and high energy absorption fenders with CCS,BV certificate.
