ISO17357-1:2014 Yokohama Rubber Fender Mooring 80kPa 4.5M

Hongruntong Marine Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap ISO17357-1:2014 Yokohama Rubber Fender Mooring 80kPa 4.5M from wholesalers

    Buy cheap ISO17357-1:2014 Yokohama Rubber Fender Mooring 80kPa 4.5M from wholesalers
    • Buy cheap ISO17357-1:2014 Yokohama Rubber Fender Mooring 80kPa 4.5M from wholesalers
    • Buy cheap ISO17357-1:2014 Yokohama Rubber Fender Mooring 80kPa 4.5M from wholesalers
    • Buy cheap ISO17357-1:2014 Yokohama Rubber Fender Mooring 80kPa 4.5M from wholesalers
    • Buy cheap ISO17357-1:2014 Yokohama Rubber Fender Mooring 80kPa 4.5M from wholesalers

    ISO17357-1:2014 Yokohama Rubber Fender Mooring 80kPa 4.5M

    Ask Lasest Price
    Brand Name : DockFender
    Model Number : DF-YRF4.5
    Certification : ISO17357-1:2014, PIANC2002
    Price : USD200 One Piece
    Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 1250 PCS Per Month
    Delivery Time : 5-6 Work Days
    • Product Details
    • Company Profile

    ISO17357-1:2014 Yokohama Rubber Fender Mooring 80kPa 4.5M

    ISO17357-1:2014 Technology Yokohama Rubber Fender Mooring 80kPa 4.5M


    Description


    Yokohama rubber fender is fully compliant with both ISO 17357:2014 standards, making it the toughest most durable product on the market. The fender shows no deterioration or variation in performance due to fatigue or extremely low temperatures, thereby removing the need for owners to make regular replacements.

    We can offer an extensive range of Yokohama rubber fender, sizing from fenders sizable for small fishing vessels to our fender suitable for the biggest tankers in the world. Additionally, we can offer vertically floating yokohama fenders, suitable for vessel whose berthing point is below the water line such as catamaran ships, semi-submersible platforms and other submersibles.


    Specifications


    Product NameISO17357-1:2014 Technology Yokohama Rubber Fender Mooring 80kPa 4.5M
    Brand NameDockFender
    Model NumberDF-YRF4500
    MaterialHigh Quality NR
    StandardPIANC, ISO17357
    CoverTyre Chain Net
    CertificatesBV, ABS, DNV, LR, SGS, RS, CCS
    OEM / ODMAvailable
    Packing DetailsPE plastic bags then to the pallet / as per your request
    Production Capacity2500 pcs per month
    Lead Time7 days for prototype tooling & samples, 14 days for production mold, 14-28 days for MOQ
    Payment TermsT/T, L/C, Paypal, Western Union
    Rubber SpecificationASTM D2000, SAE J200

    Diameter x Length
    [mm]
    50kPa
    Performance Data
    80kPa
    Performance Data
    Hull Pressure
    at GEA
    / kN / m2
    Reaction Force
    / kN
    Energy Absorption
    / kNm
    Hull Pressure
    at GEA
    / kN / m2
    Reaction Force
    / kN
    Energy Absorption
    / kNm
    1000 x 15001221823216023945
    1000 x 20001322574517433863
    1200 x 20001262976316639088
    1350 x 2500130427102170561142
    1500 x 3000153579153174761214
    1700 x 3000128639191168840267
    2000 x 35001288753081681150430
    2500 x 400013713816631801815925
    2500 x 5500148201994319526531317
    3300 x 45001301884117517124761640
    3300 x 65001463015181419139612532
    3300 x 106001585257306720869074281
    4500 x 90001465747475219275516633
    * Other size can be produced follow client's requirements.

    Features


    1. Easy to install and maintain.

    2. Reduce shock/impact force.

    3. Design and testing according to ISO17357-1:2014.

    4. Optional chain & tyres for heavy duty use.

    5. Good abrasion resistance, good resistance to UV rays.


    Applications


    ● Tankers, gas carriers and bulk cargo ships.

    ● Fast ferries and aluminum hulled vessels.

    ● Temporary of permanent installations.

    ● Rapid response and emergency fendering.

    ● As stand-off fenders to realign ships with shore facilities.


    Advantages


    ◆ Fully compliant with ISO 17357-1:2014.

    ◆ Original factory, competitive price.

    ◆ Best discount to save project budget.

    ◆ Third party strict inspection + In-house performance test.

    ◆ With excellent oil resistance, heat resistance, anti-aging properties.
