    ISO17357-1:2014 80kPa Submarine Fenders Hydropneumatic Marine Dock

    Ask Lasest Price
    Brand Name : DockFender
    Model Number : DF-3.3*6.5M
    Certification : BV, ABS, PIANC, DNV
    Price : USD630 to 2630 Per Piece
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 300 Units Per Months
    Delivery Time : 5-6 Work Days
    • Product Details
    • Company Profile

    ISO17357-1:2014 80kPa Submarine Fenders Hydropneumatic Marine Dock

    ISO17357-1:2014 Specifications Submarine Fenders Hydropneumatic Fender Marine Dock


    Description


    The DockFender floating submarine fenders were launched in 1989 and since then has been extensively used by navies across the world.

    In order to provide full protection at surface and subsurface, our submarine fenders are deployed vertically. To maintain their position, the fenders are water ballasted and also have a counterweight attached to the bottom of the fender. The weight, shape and method of deployment of the counterweight can be adjusted to suit individual situations.


    Specifications


    Product NameISO17357-1:2014 Specifications Submarine Fenders Hydropneumatic Fender Marine Dock
    Brand NameDockFender
    Model NumberDF-3.3*6.5M
    MaterialHigh Performance Natural Rubber
    StandardISO17357-1:2014, PIANC2002
    InstallVertical
    PackagePlastic Bag+Pallet
    Initial Pressure50kPa & 80kPa
    Testing Pressure250 kPa
    Energy Absorption131-2819 kJ
    Reaction Force562-4277 kN
    ColorCustomers' Requirements
    ApplicationPort, Dock, Quay, etc

    ISO17357-1:2014 80kPa Submarine Fenders Hydropneumatic Marine Dock


    Diameter x
    Length
    Initial
    Internal
    Pressure
    Ship
    Radius
    Water
    Ratio
    Guaranteed
    Energy
    Absorption
    Reaction
    Force
    at GEA
    Hull
    Pressure
    at GEA
    Deflection
    at GEA
    (mm x mm)(kPa)(mm)(%)(kJ)(kN)(kPa)(%)
    1500 x 610050300060%13156214051%
    80186754188
    1700 x 720050400065%16768213747%
    80239918184
    2000 x 600050400070%13554413141%
    80194736177
    2500 x 550050450065%22576913541%
    803221035182
    2500 x 770050450070%326101613641%
    804701368183
    3300 x 650050450075%30788712735%
    804421203173
    3300 x 1060050500065%1003213714247%
    8014292863190
    4500 x 900050500060%1439240113846%
    8020593228185
    4500 x 1200050600065%1977319814146%
    8028194277189

    Characteristics


    1. Cost effective replacement for deep water catamarans.

    2. Easily moved to provide flexibility in berthing.

    3. Easily transported to provide emergency berthing facilities.

    4. Maintenance requirement almost non-existent.

    5. Unaffected by extreme climatic conditions.


    Applications


    ● Submarines

    ● Catamaran

    ● Fast ferry

    ● Semi-submersible drilling platform


    Advantages


    ◆ US navy, ISO17357 and PIANC standard.

    ◆ High-quality rubber and H.D.G. accessories.

    ◆ Easy to move, providing berthing flexibility.

    ◆ Almost no maintenance requirements.

    ◆ Not affected by extreme climatic conditions.

    ◆ Facilitate transportation and provide emergency berthing facilities.


    Inspection & Certificate


    We use modern technology to design and manufacture, and through rigorous field testing. The following tests are to be conducted:


    - Rubber performance test including tensile, ozone and abrasion test.

    - Energy absorption and reaction test.


    Our QC department will inspect each product and offer FACTORY INSPECTION REPORT before delivery. We can also invite the third party inspection agencies including CCS, ABS, BV, LR, DNV-GL to inspect and offer certificates according to customer requirements.


    Inspect items as below:


    1. Rubber tensile, ozone and abrasion test.

    2. Rubber fender energy absorption and reaction test.


    Packing & Delivery


    Main Points--"PEEE", Professional, Efficient, Economical and Environmental.


    Duo to our products are large size and heaviness, normal we do not use packaging during shipping in order to reduce costs. So the professional packing skills are crucial, not only it need to protect our products, but also need to protect the containers, vehicles and personnel. Our core strength comes from years of work experience and a responsible attitude.
