    Marine Cell Ship Rubber Fender Height 3000mm CL800H For Dock And Jetty

    Marine Ship Dock Rubber Fender Cell Fenders CL800H For Dock and Jetty


    Description


    Cell Fenders are mostly installed for docks where Reaction force is an important criteria. Among all types of fenders, cell fenders offer minimum reaction per ton-meter energy absorbed. The very geometrical shape gives it sturdiness, shear resistance, compact structure and the capacity to absorb effectively and buckles
    radically. Cell Fenders are the most durable rubber fenders available and are currently the largest molded fenders made. In order to distribute the reaction force, cell fenders are typically supplied with large fender panels, which keep the hull pressure low. Our cell type rubber fender is installed on docks to absorb the collision energy between ship and dock at the time of berthing.


    Specifications


    Product NameMarine Ship Dock Rubber Fender Cell Fenders CL800H For Dock and Jetty
    Brand NameDockFender
    Model NumberDF-500H
    MaterialHigh Performance Natural Rubber
    Height200mm-1000mm
    Length1000-3500L
    AccessoryFront Panel, Face Panel, Bolt, Nut, Foot Rod, Foot Board
    Warranty3 Years
    After-sale ServiceFree Spare Parts
    Quality CertificationISO9001, PIANC
    Safety StandardABS, BV, SGS
    ColorCustomers' Requirements
    ApplicationPort, Dock, Quay, etc

    Marine Cell Ship Rubber Fender Height 3000mm CL800H For Dock And Jetty


    Type (mm)HØD1ØD2hholesn-Ød
    DF-CL400H400550650254Ø30
    DF-CL500H500550650254Ø32
    DF-CL630H630700840304Ø39
    DF-CL800H8009001050306Ø40
    DF-CL1000H100011001300356Ø47
    DF-CL1150H115013001500406Ø50
    DF-CL1250H125014501650456Ø53
    DF-CL1450H145016501850476Ø61
    DF-CL1600H160018002000508Ø61
    DF-CL1700H170019002100558Ø66
    DF-CL2000H200020002200558Ø74
    DF-CL2250H2250230025506010Ø74
    DF-CL2500H2500270029507010Ø90
    DF-CL3000H3000315033507512Ø90

    Features


    1. High performance, reasonable structure.

    2. Strong, well-proven design.

    3. Ideal for low hull pressure systems.

    4. Can support large panels.

    5. Strong, well-proven design.


    Applications


    ● Oil and LNG Facilities

    ● Bulk Terminals

    ● Offshore Platforms

    ● Container Berths

    ● RoRo and Cruise Terminals

    ● Multi-user Berths

    ● Ideal for ships with low hull pressure headroom


    Pre-built-in Accessories


    ◆ Bolt made of Q235 hot-dip galvanised material /1Cr13(2Cr13)1Cr18Ni9Ti/SUS304/SUS316

    ◆ Washer made of Q235 hot-dip galvanised material, 1Cr18Ni9Ti

    ◆ Pre-built-in nut made of Q235 hot-dip galvanised 1Cr18Ni9Ti/SUS304/SUS316

    ◆ Foot rod: Q235

    ◆ Foot board: Q235
