    2.0*3.5M Floating Pneumatic Rubber Fenders 50kPa 80kPa For Ship Docking

    Ask Lasest Price
    Brand Name : DockFender
    Model Number : DF-PRF2.0*3.5M
    Certification : PIANC, ISO17357
    Price : EUR 220 to 2200 Per Piece
    Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 1260 Pcs Per Month
    Delivery Time : 7 Work Days
    • Product Details
    • Company Profile

    2.0*3.5M Floating Pneumatic Rubber Fenders 50kPa 80kPa For Ship Docking

    2.0*3.5M Pneumatic Rubber Fender ISO17357 Standard 80kPa Boat Floating


    Description


    Pneumatic rubber fender can be easily handled and installed with guy-rope or guy-chain because of their lightweight. It can resist the shearing force and maintain energy absorption level under inclined compression up to 15 degrees. Meanwhile, provide low and comparatively even hull pressure.

    Pneumatic rubber fender is known as Pneumatic fenders or Pneumatic-type pneumatic fenders. Floating pneumatic rubber fender is made of the synthetic-cord-reinforced rubber sheet with compressed air inside to enable it to float on the water and work as a shock absorbed between two ships (ship-to-ship), or between ships and berthing structures when they come alongside each other on the water. Pneumatic rubber fender is manufactured and tested to ISO 17357.


    Specifications


    Item2.0*3.5M Pneumatic Rubber Fender ISO17357 Standard 80kPa Boat Floating
    MaterialHigh Quality NR/NBR/SR
    TypeCTN, 80kPa
    Neoprene

    Thickness: 1.0- 50.0mm

    Color: Black, green, red, yellow, white

    Diameter0.5m-4.5m
    Elongation≥400
    Density95±5
    Tensile Strength≥18
    Hardness65 +/- 10 Shore A or according to your requirement
    ColorAs per your request
    Lead Time2-3 weeks
    Production Capacity1800 Pcs per month
    PackagePP bag or wooden pallet or as required
    Payment termT/T
    UseSTS, STD
    FeatureWaterproof, Shockproof, Good Elastic, Soft
    AdvantageWe can composite the fabric with different kinds of fabric to make the material suitable for different types of products

    Normal Size

    Inner Pressure: 50Kpa

    60% deflection

    Inner Pressure: 80Kpa

    60% deflection

    DiameterLengthReaction ForceEnergy AbsorptionHull AbsorptionReaction ForceEnergy AbsorptionHull Absorption
    mmmmkNkNmkPakNkNmkPa
    5001000646132858174
    60010007481269811166
    70015001371713518024177
    100015001823212223945160
    100020002574513233863174
    120020002976312639088166
    13502500427102130561142170
    15003000579152132731214174
    17003000639191128840267168
    200035008753081281150430168
    2500400013816631371815925180
    25005500201994314826531317195
    330045001884117513024761640171
    330065003015181414639612532191
    3300106005121309017166124294220
    450070004660381618658664945233
    450090005747475214675516633192
    45001200079846473154104909037202

    Features


    1. As a protective medium is suitable for ship-to-ship contact, ship to dock and ship to berthing.
    2. It is light weight, portable and floatable, can be installed, replaced easily and reused 6-8 years without misuse.
    3. We have provided pneumatic fenders to marine service and offshore service for varieties ships.
    4. All kinds of foam-filled marine fenders can be available.


    Applications


    ● Tankers, Gas Carriers and Bulk Cargo Ships.

    ● Fast ferries and aluminum hulled vessels.

    ● Temporary of permanent installations.

    ● Ships (ship-to-ship), or between ships and berthing structures.


    Advantages


    ◆ Guaranteed for two years against defects in workmanship and material.

    ◆ Free repair during the guarantee if come out quality issues.

    ◆ The repair technology supply for free.

    ◆ We provide rental and old for new service.

    ◆ The Lifespan of our fender is longer than 20 years.
