    Iso17357 Yokohama Rubber Fender Marine Floating Pneumatic For Vessels

    Ask Lasest Price
    Brand Name : Dock-Fender
    Model Number : DF-2.0x3.5M
    Certification : ABS, DNV, LR, BV, SGS
    Price : $60-$190
    Payment Terms : T/T, L/C
    Supply Ability : 1360 Pcs/Month
    Delivery Time : 5-7 Days
    • Product Details
    • Company Profile

    Iso17357 Yokohama Rubber Fender Marine Floating Pneumatic For Vessels

    ISO17357 Marine Yokohama Floating Pneumatic Rubber Fenders for Vessels


    Description


    Pneumatic fenders, also known as air-filled fenders or inflatable fenders, are a type of protective barrier used in marine environments. Made from reinforced rubber and tyre cord layers, these fenders are designed to absorb the impact energy and reduce the risk of damage to ships, ports, and offshore platforms during mooring and ship-to-ship transfer operations.


    Pneumatic fenders are inflated with compressed air, creating a high-pressure cushion that allows them to absorb impacts and distribute the resulting force evenly. They are available in a range of sizes and configurations to suit various vessel sizes and mooring configurations.


    One of the primary advantages of pneumatic fenders is their relatively low weight and ease of deployment. Their inflatable design also makes them easy to store when not in use. In addition, pneumatic fenders offer excellent durability and resistance to weather and sea conditions, making them a popular choice for marine and offshore environments.


    Overall, pneumatic fenders provide an effective and reliable means of protecting vessels and marine structures from damage during mooring and transfer operations.


    Iso17357 Yokohama Rubber Fender Marine Floating Pneumatic For Vessels


    Specifications


    Product NameISO17357 Marine Yokohama Floating Pneumatic Rubber Fenders for Vessels
    MaterialNatural Rubber
    Diameter500mm-4500mm (Other size can be customized)
    Length1000mm-12000mm (Other size can be customized)
    Initial Pressure50kPa, 80kPa
    StandardISO17357-1:2014
    Energy Absorption6-9037KN.M
    Reaction Force64-1049KN
    Product Life12-15 Years
    Temperature-30℃ to 70℃
    LogoAvailable
    ApplicationSTS Operations, Dock Bumper

    Iso17357 Yokohama Rubber Fender Marine Floating Pneumatic For Vessels


    SpecificationInitial Pressure 50KPaInitial Pressure 80KPa
    D*L(mm)R(KN)GEA (KJ)R(KN)GEA (KJ)
    500*1000646858
    600*10007489811
    700*15001371718024
    1000*15001823223945
    1000*20002574533863
    1200*20002976339088
    1350*2500427102561142
    1500*3000579153761214
    1700*3000639191840267
    2000*3000750265985368
    2000*35008753081150430
    2500*400013816631815925
    2500*5500201994326531317
    3000*50002104121027091571
    3000*60002583148532921888
    3300*45001884117524761640
    3300*65003015181439612532
    3300*106005257306769074281
    4500*65004150343254534790
    4500*90005747475275516633
    4500*1200079846473104909037

    Features


    1. High Energy Absorption: Pneumatic fenders are designed to absorb high levels of impact energy, thanks to their inflatable design and cushioning effect.


    2. Even Pressure Distribution: Pneumatic fenders distribute the impact force evenly across their entire surface, reducing the risk of concentrated impact damage.


    3. Low Reaction Force: The reaction force generated by pneumatic fenders is typically low, which reduces the risk of damage to ships and other vessels during mooring and transfer operations.


    4. Rubber Construction: Pneumatic fenders are made from reinforced rubber materials that offer excellent durability and resistance to the harsh marine environment.


    5. Low Maintenance Requirements: Pneumatic fenders require minimal maintenance, and are easy to clean and repair if necessary.


    6. Lightweight and Easily Deployed: Pneumatic fenders are relatively lightweight and easy to deploy, making them an ideal choice for a range of marine and offshore applications.


    7. Customizable Sizes and Shapes: Pneumatic fenders come in a range of customizable sizes and shapes to match the specific requirements of different marine installations.


    Applications


    Ship-to-ship transfers
    Mooring and Berthing
    LNG Terminals
    Offshore Wind Farms
    Floating Platforms
    Breakwater Construction
    Pleasure Craft


    Advantages

    High-Quality Materials: The company should use high-quality materials to manufacture their pneumatic fenders, such as reinforced rubber materials, to ensure durability and reliability.


    Customization: The company should offer a range of customizable sizes and shapes to match the specific requirements of their clients' marine installations.


    Technical Expertise: The company should have technical expertise in manufacturing, testing, and deploying pneumatic fenders to provide optimal and effective solutions to clients.


    Comprehensive Services: The company should offer comprehensive services such as installation, maintenance, repair, and replacement of pneumatic fenders to ensure optimal performance and longevity.


    Competitive Pricing: The company should offer competitive pricing to make their pneumatic fenders affordable for clients while maintaining high-quality standards.


    Fast Delivery: The company should be able to offer fast delivery times, reducing the waiting time for clients' orders and ensuring timely deployments.


    Proven Track Record: The company should have a proven track record of delivering high-quality and reliable pneumatic fenders to clients in the marine and offshore industries.
