    Iso 17357 Anti Explosion Yokohama Rubber Fender Marine Floating Ship

    Ask Lasest Price
    Brand Name : DockFender
    Model Number : DF-YF4500*9000MM
    Certification : ISO17357-1:2014, PIANC2014
    Price : USD200-900 One Piece
    Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 2230 PCS Per Month
    Delivery Time : 5 Days
    MOQ : 1 Piece
    • Product Details
    • Company Profile

    Iso 17357 Anti Explosion Yokohama Rubber Fender Marine Floating Ship

    ISO 17357 Pneumatic Yokohama Rubber Fender Marine Floating Ship Fender


    Description


    Yokohama rubber fenders are a type of marine fender system used to protect ships and other vessels from damage during berthing or mooring operations. They are made from high-strength synthetic rubber and reinforced with nylon cords, which provide excellent shock absorption and energy absorption characteristics.

    Yokohama rubber fenders are typically cylindrical in shape and come in various sizes and designs to suit different vessel types and berthing conditions. They are commonly used in ports, harbors, and offshore facilities around the world.

    Yokohama rubber fenders are easy to install and maintain, and they offer a cost-effective solution for protecting vessels from impact damage. They are also highly durable and resistant to environmental factors such as UV radiation, saltwater, and extreme temperatures.


    Specifications


    Product NameISO 17357 Pneumatic Yokohama Rubber Fender Marine Floating Ship Fender
    Construction MaterialNatural Rubber
    ColorBlack, Grey, or as required
    SizeDiameter 0.3M-4.5M, Length 0.5M-12.0M
    Working pressure50kPa, 80kPa
    Applicationused for ship and dock
    CertificateISO9001-2008 BV CCS CCC
    PackingStandard Package
    Warranty2 years

    Diameter x Length
    [mm]
    50kPa
    Performance Data
    80kPa
    Performance Data
    Hull Pressure
    at GEA
    / kN / m2
    Reaction Force
    / kN
    Energy Absorption
    / kNm
    Hull Pressure
    at GEA
    / kN / m2
    Reaction Force
    / kN
    Energy Absorption
    / kNm
    1000 x 15001221823216023945
    1000 x 20001322574517433863
    1200 x 20001262976316639088
    1350 x 2500130427102170561142
    1500 x 3000153579153174761214
    1700 x 3000128639191168840267
    2000 x 35001288753081681150430
    2500 x 400013713816631801815925
    2500 x 5500148201994319526531317
    3300 x 45001301884117517124761640
    3300 x 65001463015181419139612532
    3300 x 106001585257306720869074281
    4500 x 90001465747475219275516633
    * Other size can be produced follow client's requirements.

    Constructions


    Out Rubber

    Out rubber layer that covers the outside of the fender to protect the cord layers and the inner liner rubber from abrasion and other external forces.


    Inner Rubber

    Liner of a rubber membrane that seals the pressurized air inside the fender.


    Synthetic-Tyre-Cord Reinforcement

    Layer made of synthetic tyre-cord fabric,which maintains the internal air pressure of the fender.


    Applications


    -Oil and gas tankers
    -Fast ferries and aluminium vessels
    -Temporary and permanent installations
    -Rapid response and emergencies
    -Can support large panels
    -Very low reaction and hull pressure
    -Suitable for small and large tidal ranges
    -Maintains large clearances between hull and structure


    Advantages


    ◆ Fully compliant with ISO 17357-1:2014

    ◆ Original factory, competitive price

    ◆ Best discount to save project budget

    ◆ Third party strict inspection + In-house performance test

    ◆ With excellent oil resistance, heat resistance, anti-aging properties
